StarTech.com Dual-Bay M.2 NVMe SSD To PCIe X8 Removable Mobile Rack; Bifurcation Req – 2M2-REMOVABLE-PCIE
STARTECH DUAL-BAY M.2 NVME SSD TO PCIE X8 REMOVABLE MOBILE RACK; BIFURCATION REQ
Features
Technical Specifications
| Brand | : | StarTech.com |
| Manufacturer Part Number | : | 2M2-REMOVABLE-PCIE |
| Product Category | : | SSD & Hard Drives |
| UPC | : | 065030904650 |
| Type | : | Backplane |
| Product color | : | Black |
| Number of SSDs supported | : | 2 |
| SSD interface | : | M.2 |
| SSD form factor | : | M.2 |
| Hot-swap | : | Yes |
| Number of fans | : | 2 fan(s) |
| Data transfer rate | : | 128 Gbit/s |
| LED indicators | : | Yes |
| Key lock | : | Yes |
| RAID support | : | No |
| S.M.A.R.T. support | : | Yes |
| TRIM support | : | Yes |
| Mean time between failures (MTBF) | : | 40000 h |
| Host interface | : | PCI Express |
| PCIe version | : | 4.0 |
| Width | : | 186 mm |
| Depth | : | 121 mm |
| Height | : | 19 mm |
| Weight | : | 500 g |
| Package width | : | 230 mm |
| Package depth | : | 151 mm |
| Package height | : | 46 mm |
| Package weight | : | 500 g |
| Quick start guide | : | Yes |
| Number of lock keys included | : | 2 pc(s) |
| Number of screws | : | 2 |
| Storage temperature (T-T) | : | 0 - 50 °C |
| Operating temperature (T-T) | : | -10 - 60 °C |
| Operating relative humidity (H-H) | : | 10 - 60% |
| Compliance certificates | : | RoHS |
| Quantity per master (outer) case | : | 28 pc(s) |
| Master (outer) case width | : | 325 mm |
| Master (outer) case length | : | 485 mm |
| Master (outer) case height | : | 258 mm |
